Scope of application:
Various plastic shells, automatic nozzle cutting process on the side of injection molding machine
advantage:
1. The production process is automated, saving labor.
2. The machine is stable and reliable, with strong versatility.
| Project | Specification | Describe |
| Dimensions | Length 1200mm*width 500mm*height 1600mm | |
| Fits product specification | Length 180mm*width 85mm | |
| Robot position accuracy | ±0.1mm | |
| Control System | Yuehe machine edge cutting machine operating system | |
| Power requirements | 220V，50HZ | |
| Power | 0.5KW | |
| Air pressure requirements | 0.5~0.8MPA | |
| Weight | 150Kg | |
| Capacity | 450-900PCS/H | The efficiency of the injection molding machine determines |
| Equipment cost recovery cycle | 4 months | According to 80% equipment utilization rate |
|
