Scope of application:
Resistance test of various mobile phone hardware shells and tablet computer hardware shells.
advantage:
1. The automatic operation of the equipment replaces labor, and the production capacity is 1200pcs/H.
2. The resistance test accuracy is 1 milliohm, and supports multi-point and multi-channel testing, with a maximum support of 512 points.
3. The equipment can be placed next to the assembly line, which is convenient for erection, debugging and maintenance.
4. The modular design of the equipment makes it easy to replace the part number. Only the part of the mechanism in contact with the product needs to be replaced,
which saves the cost of replacing the part number.
5. The equipment can automatically place the defective products in the defective area to avoid mixing.
6. The equipment covers an area of only 0.82m2, saving space and improving space utilization.
| Project | Parameter | Describe |
| Dimensions | Length 817mm*width 954mm*height 1412mm | |
| Detectable product size | Length 180mm, width 85mm | Customizable |
| Test Range | 0~100 megohm | |
| Test accuracy | 0.01 Euro | |
| Test points | Standard 128 points, expandable to 512 points | |
| Test method | 2-wire/4-wire test | |
| Control System | Yuehe automatic resistance testing machine control system V1.0 | |
| Power requirements | AC220V 50~60HZ | |
| Power | 400W | |
| Air pressure requirements | 0.5-0.8MPA | |
| Weight | 200KG | |
| Capacity | 1200PCS/H | |
| Equipment cost recovery cycle | 4 months | Calculated at 80% equipment utilization rate |
|
